Technical Specification
Technical Specification
| Parameter | AIHB-24 / 30 | AIHB-36 / 39 | AIHB-42 |
|---|---|---|---|
| Dia of Saw Wheel | 24″ / 30″ | 36″ / 39″ | 42″ |
| Size of Trolley | 8′ × 3′ | 12′ × 3.5′ | 12′ × 3.5′ |
| Length of Rail | 40 Feet | 60 Feet | 60 Feet |
| Max. Cutting Dia. | 3.5′ | 5.5′ | 5.5′ |
| Required Power | 5 & 7.5 HP | 12.5 HP / 15 HP | 15 HP |
| Speed of Saw Wheel | 540 RPM | 576 RPM | 576 RPM |
